MCN65LM
Construction 65mm (2-1/2") Paper/Plastic Joist Hanger Nailer (long Magazine)
The MCN65LM is a professional-grade joist hanger nailer engineered to excel in all metal connector applications. With an impressive power-to-weight ratio of 675 inch-lbs at just 6.2 lbs (2.8 kg), it is ideal for installing a wide range of joist hangers, from standard models to heavy-duty applications. Whether working with angled joist hangers, corner installations, or specialized joist hangers for stairs, its exposed nail tip design ensures precise placement every time. Compatible with standard joist hanger nail sizes, the lightweight aluminum magazine and integrated check pawl effectively prevent jams while maintaining superior balance and maneuverability. The MCN65LM meatal connector nailer features Its long magazine design enhancing efficiency, particularly in high-volume applications. Spotlighted with a rotatable rafter hook for added convenience when moving between joists, and its low nail lockout mechanism prevents dry fires during intensive joist hanger installations. This comprehensive design makes it the perfect positive placement nailer for demanding projects.
Show more
Show less
- APPLICATIONS
- Strapping
- Joist Hangers
- Hurricane Ties
- Rafter Ties
- Post Bases
- Caps Anchors
FEATURES
Exposed nail tip design for fast and precise nailing of 2 ½” and 1 ½” nails
Integrated check pawl designed to prevent jams
Low nail lockout prevents dry fires
Rotatable, steel rafter hook provides workplace convenience.
Lightweight Aluminum magazine for balance and maneuverability
Extended magazine holds up to 55 nails. If you need a standard magazine model, please visit MCN65 metal connector nailer.
TOOL SPECIFICATION
Weight | 2.8 kgs (6.2 lbs) |
---|---|
Height | 312mm (12.3") |
Width | 141.5mm (5.6") |
Length | 434.5mm (17.1") |
Operating Pressure | 5~8 bar (70~120 psi) |
Driving Power | 675 In-lbs |
Air Consumption (@90psi) | 1.7L/sec (3.6 cfm) |
FASTENER SPECIFICATION
Type | 34° Paper Collated & Plastic Collated Nails |
---|---|
Loading Capacity | 55 |
Nail Length | 38 ~ 65mm (1-1/2" ~ 2-9/16") |
Nail Head Dia. | 7.0~8.5mm (0.276~0.335") |
Nail Shank Dia. | 3.3 ~ 4.1mm (0.131" ~ 0.162") |
